Cow Dung Slurry Pump



Cow Dung Slurry Pump can be lined with metal,rubber ,ceramic ,stainless steel.

Parameters of cow dung slurry pump
Size range (outlet):----- 1'' to 18'' (25 mm to 450 mm)

Capacity:-------------- up to 22,000 gpm ( 5,000 m3/hr )

Head: -----------------up to 240 ft (73 m )

Pressure: --------------up to 300 psi (2,020 kPa)

Features of cow dung slurry pump

1). Cantilever, horizontal centrifugal cow dung Slurry pump

2). Better wear-resistance and corrosive resistance

3). Frame plate for type pumps have replaceable wear-resistant metal( high chrome alloy ) liners or rubber liners. The impellers are made of wear-resistant metal( high chrome alloy ) or Natural rubber .

4). In allowable pressure range, it can be used in series in stages, and allowable maximum working pressure is 3.6Mpa.

5). Expeller seal, mechanical seal and packing seal are available .

6). The discharge branch can be positioned at interval of 45 degrees by request and oriented to any eight positions to suit installations and applications.

7). To adapt to convey heavy abrasion, high concentration dreg , NH slurry pump's body is used double-deck,construction , in other words, being made of inside lining and outside shell.

The self priming slurry pump body is constructed of sturdy, corrosion-resistant materials to prevent wear and tear over time. The impeller is made of high-strength alloy steel to withstand the abrasive and corrosive nature of the slurry.

Furthermore, we employ advanced manufacturing techniques to ensure precise assembly and calibration of each self priming slurry pump . This results in optimal performance and efficiency, reducing the risk of breakdowns and minimizing the need for maintenance.

Should any maintenance be required, our pumps are designed for easy access and simple repairs. This further lowers maintenance costs and downtime, ensuring the reliability and longevity of our slurry pumps.
Working site of cow dung slurry pump:
A sand slurry pump is used for pumping sediment-laden water in applications such as dredging, mining, and wastewater treatment. The pump is designed to handle abrasive and viscous slurries, making it an ideal choice for these types of applications.

Performance Of COW DUNG SLURRY PUMP
Type	Max. power	Capacity	Head	Impeller	Max. particle size
				Quantity of vanes
	kw	(m³/h)	(m)		(mm)
1.5x1B-MAH	15	3.6-21.6	6-65	5	14
1.5x2B-MAH	15	7.2-48.6	5-62	5	19
2x3C-MAH	30	21.6-88.56	15-40	5	21
4x3C-MAH	30	28.8-158.4	7-53	5	28
6x4D-MAH	60	72-331.2	11-64	5	44
8x6E-MAH	120	126-720	6-62	5	63
10x8ST-MAH	560	216-1051.2	9-64	5	76
12x10ST-MAH	560	316.8-1620	10-66	5	86
14x12ST-MAH	560	504-2455.2	10-75	5	90

The operation of a sand slurry pump involves the following steps:

1. Priming: The pump must be primed with water to expel any air and create a vacuum, which will allow the pump to draw in slurries from the source.

2. Suction: The pump pulls in the slurry through its suction port, mixing it with water and creating a slurry solution.

3. Impeller: The impeller is a rotating component that creates the centrifugal force needed to move the slurry through the pump's volute.

4. Discharge: The slurry is then discharged through the pump's outlet and transported to the destination.

5.Maintenance: Regular maintenance is necessary to ensure the pump is operating at peak performance. This includes regular cleaning of the pump, monitoring of the impeller and other components, and replacing any worn-out parts.
