Coal Mine Underground Multistage Pump

Modo Pump has been focused on coal mine underground multistage pump manufacturing and selling for many years, which is known as a professional manufacturer and supplier of various quality pumps in China. We have gathered many professional and experienced staff, as well as advanced equipment in our factory. Welcome to buy our coal mine underground multistage pump and check the price list with us.



Coal mine underground multistage pump

ModO Pump is mainly involved in the project of underground main drainage pump in coal mine, providing customers with self balancing mining multi-stage centrifugal pump and water pump motor, which involves the minimum requirements for the design, manufacture, supply, installation and other related services of the main drainage pump in the water pump house.



Service environment of underground dewateringpump:



1. Water quality: mine water, weakly alkaline, containing slag, sediment and other impurity particles, easy to scale.



2. Working environment: the chamber of the central water pump room in the middle 0m section of the coal mine is dark and humid.



3. Equipment transportation conditions: the shaft diameter is 6.5m, the section size of horse head gate is 4.5 * 3.7m, the section size of monorail roadway is 4.0 * 3.5m, the section size of double rail roadway is 5.0 * 3.5m, the section size of material channel is 3.9 * 3.6m, and the section size of inclined transport roadway is 3.3 * 3.2m.



Technical requirements for Coal mine underground multistage pump



1. The structural form of the water pump is self balancing, horizontal multi-stage high-efficiency and energy-saving centrifugal pump, and the impellers are symmetrically arranged without balance disk system.



2. The water pump shall be designed with reasonable structure, good cavitation performance, high efficiency, reliable and stable operation, and can effectively withstand the impact of water hammer in case of mine power failure.



3. The pump rotor shall not move axially, and the flow channel shall always be centered, so that the pump can always operate in the high efficiency area and the efficiency curve is flat.



4. The complete water pump shall have high anti rust performance. All castings shall be free of slag inclusion, pores, sand holes and other defects, and the appearance shall be flat. The surface shall be sand blasted and derusted to SA2 Grade 5, apply two coats of epoxy resin primer and finish paint, and the paint film thickness is greater than 250um





Through many times of communication and confirmation with customers, our technicians finally selected the self balancing multistage pump with the following parameters：

Model: ZD45-50X4

Flow rate: 45m3/hr

Head: 200m

Speed: 3000rpm

Motor power: 45kw

Inlet/Outlet: 80mm

Material: Hi- hard iron
