Mineral Processing Horizontal Slurry Pump

Name: Mineral Processing Horizontal Slurry Pump
Brand: MODO
SKU: 28303290

Heavy Duty Mining Horizontal Single Stage Slurry Pump Introduction: MAH series slurry pump is designed for the continuous pumping of high abrasive, high density slurries with minimal maintenance requi rements. It will maintain high efficiency over the wear life of its components. This series is...

Send Inquiry

Product Details

Feature:

1. centrifugal slurry pumps and spare parts can fully interchange with world famous brand.

2. These pumps are of heavy-duty construction, designed for continuous pumping of highly abrasive and corrosive slurries.

3. They feature a wide choice of replaceable abrasion resistant metal or moulded elastomer casting liners and Impellers, which are all interchangeable within a common casting assembly.

4. Wear -resistant Metal Liner and Rubber Liner available

5.Seal Type: gland Seal , Expeller Seal and Meachnical seal

Specification:

Type	Allowable Mating Max. Power(Kw)	Clear Water Performance					Impeller
Type	Allowable Mating Max. Power(Kw)	Capacity/Q m³/hr	Head/m	Speed/rpm	Max Efficiency/%	NPSH/m	Nos of Vane	Impeller Diameter/mm
1.5X1-MAH	15	12.6--28.8	6--68	1200--3800	40	2--4	5	152
2X1.5-MAH	15	32.4--72	6--58	1200--3200	45	3.5--8	5	184
3X2-NP-MAH	30	39.6--86.4	12--64	1300--2700	55	4--6	5	214
4X3-MAH	30	86.4--198	9--52	1000--2200	71	4--6	5	245
6X4-MAH	60	162--360	12--56	800--1550	65	5--8	5	365
8X6-M-AH	300	360--828	10--61	500--1140	72	2--9	5	510
10X8-MAH	560	612--1368	11--61	400--850	71	4--10	5	686
12X10-MAH	560	936--1980	7--68	300--800	82	6	5	762
14X12-MAH	560	1260--2772	13--63	300--600	77	3--10	5	965
16X14-MAH	1200	1368--3060	11--63	250--550	79	4--10	5	1067
18X16-MAH	1200	2520--5400	13--57	200--400	85	5--10	5	1370
