Slurry Mud Pump

Modo Pump has been focused on slurry mud pump manufacturing and selling for many years, which is known as a professional manufacturer and supplier of various quality pumps in China. We have gathered many professional and experienced staff, as well as advanced equipment in our factory. Welcome to buy our slurry mud pump and check the price list with us.



Raw material Of slurry mud pump is an innovative product independently designed and developed by our company in order to meet the requirements of users and adapt to the working conditions of conveying strong corrosion and high wear media. The flow parts Of Raw material Of slurry mud pump are all made of wear-resistant corundum material, which has the characteristics of wear resistance and corrosion resistance, high efficiency and energy saving, stable operation and convenient maintenance.
Size range (outlet):------ 1'' to 18'' (25 mm to 450 mm)
Capacity:----------------- up to 22,000 gpm ( 5,000 m3/hr )
Head: --------------------- up to 240 ft (73 m )
Pressure: ----------------- up to 300 psi (2,020 kPa)

Description of slurry mud pump:

Available models of Raw material Of slurry mud pump:

Type	Max. power	Capacity	Head	Speed	Max.Eff	NPSH	Impeller Dia.	Max.particle size
	(kw)	(m³/h)	(m)	(r/min)	(%)	(m)	(mm)	(mm)
MAH1.5-1	15	12-28	6-65	1200-3800	40	2-4	150	14
MAH2-1.5	15	32-72	6-58	1200-3200	45	3.5-8	185	19
MAH3-2	30	39-86	12-64	1300-2700	55	4-6	215	25
MAH4-3	60	86-198	9-52	1000-2200	71	4-5	245	28
MAH6-4	120	162-360	12-56	800-1500	68	5-8	365	44
MAH8-6	120	360-830	10-61	500-1140	72	2-9	510	63
MAH10-8	260	612-1368	11-61	400-850	71	4-10	685	76
MAH12-10	560	936-1980	7-68	400-750	82	1-5	760	86
MAH14-12	560	1260-2772	13-63	300-600	77	3-10	965	90

How to select a suitable slurry mud pump:
Selecting the right sewage slurry mud pump can be a daunting task, but with a little knowledge and understanding of the pump’s capabilities, it can be made easier. The sewage slurry mud pump plays a critical role in the treatment of wastewater and other industrial residues. It is crucial that the pump chosen is dependable, efficient and can handle the specific application.

The first step in selecting a sewage slurry mud pump is to understand the nature of the material you need to pump. Some wastewater contains solids or large debris that cannot be moved with a standard pump. Therefore, you will need to choose a slurry mud pump with a specific design and features that can handle the material. For instance, a centrifugal pump may work for pumping clear liquids, but it may not be suitable for viscous sludge.

Another factor to consider is the flow rate required. The flow rate determines the amount of liquid you need to transport per unit of time. The higher the flow rate, the more powerful the pump needs to be. The size of the pipe and distance also plays a key role in determining the flow rate.

The pump’s efficiency is also an important aspect when selecting the right unit. The more efficient the slurry mud pump, the less energy and maintenance it will require. Consider slurry mud pumps that are built with high-quality materials and are designed to resist corrosion and wear.

Other factors to consider include the type of power source, the manufacturer's reputation, and the cost of the pump. Choose a manufacturer with a long-standing reputation for quality and reliability. The cost of the pump should also be a consideration, but it should not be the only factor. A cheaper slurry mud pump may require more maintenance in the long run, costing more in the long term.

In conclusion, selecting the right sewage slurry mud pump requires careful consideration of many factors, including the material being pumped, the flow rate required, the efficiency of the pump, the manufacturer's reputation, and the cost. With a little research, you can find a slurry mud pump that will meet your needs and last for many years.
